JIANGSU HANYUN HYDRAULIC COMPONENT MFG.CO.,LTD.

A

B

C

D (HHCS)

INCH

Sae 3000Pcl

HY300-8-8

1/2

1/2

66.04

30.18

48.28

3/4-16

HY300-8-12

1/2

3/4

69.85

38.10

53.09

3/4-16

HY300-12-12

3/4

3/4

69.85

38.10

48.01

11/16-12

HY300-16-12

1

3/4

69.85

38.10

46.74

15/16-12

HY300-12-16

3/4

1

71.12

44.45

49.28

11/16-12

HY300-16-16

1

1

71.12

44.45

48.01

15/16-12

HY300-20-16

11/4

1

71.12

44.45

46.74

15/8-12

HY300-12-20

3/4

11/4

71.12

50.80

49.28

11/16-12

HY300-16-20

1

11/4

71.12

50.80

48.01

15/16-12

HY300-20-20

11/4

11/4

71.12

50.80

46.74

15/8-12

HY300-24-20

11/2

11/4

86.36

50.80

58.93

17/8-12

HY300-16-24

1

11/2

84.58

50.45

61.47

15/16-12

HY300-20-24

11/4

11/2

85.85

60.33

61.47

15/8-12

HY300-24-24

11/2

11/2

88.90

60.33

61.47

17/8-12

HY300-32-24

2

11/2

106.68

60.33

72.90

21/2-12

HY300-20-32

11/4

2

91.44

71.37

67.06

15/8-12

HY300-24-32

11/2

2

94.74

71.42

67.06

17/8-12

HY300-32-32

2

2

101.09

71.42

67.06

21/2-12

HY300-32-40

2

21/2

101.09

84.12

67.06

21/2-12

A

B

C

D (HHCS)

INCH

Sae 3000Pcl

HY302-8-8

1/2

1/2

63.25

30.18

48.28

3/4-16

HY302-12-12

3/4

3/4

66.29

38.10

48.01

11/16-12

HY302-16-12

1

3/4

73.15

38.10

54.86

15/16-12

HY302-12-16

3/4

1

69.60

44.45

51.31

11/16-12

HY302-16-16

1

1

66.29

44.45

48.01

15/16-12

HY302-20-16

11/4

1

79.50

44.45

61.21

15/8-12

HY302-16-20

1

11/4

69.60

50.80

51.31

15/16-12

HY302-20-20

11/4

11/4

79.50

50.80

61.21

15/8-12

HY302-24-20

11/2

11/4

87.12

50.80

68.83

17/8-12

HY302-16-24

11/4

11/2

83.82

60.45

65.53

15/16-12

HY302-20-24

11/4

11/2

83.82

60.33

65.53

15/8-12

HY302-24-24

11/2

11/2

79.76

60.33

61.47

17/8-12

HY302-24-32

11/2

2

96.27

71.42

77.98

17/8-12

HY302-32-32

2

2

92.20

71.42

73.91

21/2-12

HY302-40-40

21/2

21/2

107.44

84.07

78.23

3-12

HY302-48-48

3

B

114.30

101.60

85.34

31/2-12

HY302-64-64

4

4

105.16

127.00

73.41

41/2-12

A

B

C

D (HHCS)

INCH

Sae 6000Pcl

HY600-8-8

1/2

1/2

66.29

31.75

49.53

3/4-16

HY600-12-12

3/4

3/4

69.85

41.28

48.01

11/16-12

HY600-16-12

1

3/4

69.85

41.28

46.74

15/16-12

HY600-20-12

11/4

3/4

77.47

41.28

53.09

15/8-12

HY600-12-16

3/4

1

71.12

47.63

49.28

11/16-12

HY600-16-16

1

1

71.12

47.63

48.01

15/16-12

HY600-20-16

11/4

1

71.12

47.63

46.74

15/8-12

HY600-16-20

1

11/4

77.47

53.98

54.36

15/16-12

HY600-20-20

11/4

11/4

77.47

53.98

53.09

15/8-12

HY600-24-20

11/2

11/4

83.82

53.98

56.39

17/8-12

HY600-16-24

1

11/2

84.58

63.50

61.47

15/16-12

HY600-20-24

11/4

11/2

88.90

63.50

64.52

15/8-12

HY600-24-24

11/2

11/2

88.90

63.50

61.47

17/8-12

HY600-32-24

2

11/2

125.48

63.50

91.69

21/2-12

HY600-24-32

11/2

2

126.49

79.38

73.41

17/8-12

HY600-32-32

2

2

107.44

79.38

73.41

21/2-12

A

B

C

D (HHCS)

INCH

Sae 6000Pcl

HY602-8-8

1/2

1/2

63.50

31.75

49.53

3/4-18

HY602-12-12

3/4

3/4

66.55

41.28

48.01

11/16-12

HY602-16-12

1

3/4

73.15

41.28

54.61

15/16-12

HY602-12-16

3/4

1

69.85

47.63

51.31

11/16-12

HY602-16-16

1

1

66.55

47.63

48.01

15/16-12

HY602-20-16

11/4

1

87.38

47.63

68.83

15/8-12

HY602-16-20

1

11/4

79.25

53.98

60.71

15/16-12

HY602-20-20

11/4

11/4

76.20

53.98

57.66

15/8-12

HY602-24-20

11/2

11/4

87.38

53.98

68.83

17/8-12

HY602-20-24

11/4

11/2

84.70

63.50

65.53

15/8-12

HY602-24-24

11/2

11/2

81.03

63.50

62.48

17/8-12

HY602-24-32

11/2

2

99.06

79.38

80.52

17/8-12

HY602-32-32

2

2

95.25

79.38

76.71

21/2-12
